Product Description:
Features:
- Product Name: Low Pressure Die Casting Machine
- Total Weight: 13T
- Total Power: 125KW
- Air Pressure Compressed Air Consumption: 15m³/H
- Max. Force of Ejector: 500kg
- Gas Pressure: 0.5bar
- Metal Dia Casting Machine
- Low Pressure Casting Machine
Technical Parameters:
| Properties | Parameters |
| Equipment Size:L*W*H | 5200*5000*3600mm |
| Total Weight | 13T |
| Total power | 125KW |
| Voltage | 380V |
| Max. Die Dimensions | 600*400*240mm |
| Max. Die Thickness | 2*120mm |
| Max. Die Opening stroke | 370mm |
| Max.Die Weight | 200Kg |
| Max. force of die closing | 2400KG |
| Max. force of ejector | 500KW |
| Max. die ejector stroke | 48mm |
| Furnace Melting rate | 350KG/H |
| Furnace Capacity | 1800KG |
| Furnace Inductors | 3*35KW |
| Hydraulic Motor Power | 8.7KW |
| Hydraulic Rated Pressure | 8Mpa |
| Hydraulic fluid temperature | ≤52℃ |
| Cooling system Water PH value | 7~8.5 |
| Cooling system Pressure | 3-5bar |
| Cooling system Temp. | 20±2℃ |
| Cooling system Flow | ≥400L/Min ≤600L/Min |
| Air pressure Compressed air pressure | 0.5-0.6Mpa |
| Air pressure Compressed air consumption | 15m³/H |
Applications:
The DZ RD-5040-S Low Pressure Die Casting Machine is a great choice for those looking for a reliable, efficient and cost-effective metal die casting solution. This machine is certified with CE ISO and has a max die thickness of 2*120mm. It features 3*35KW furnace inductors, a furnace capacity of 1800KG and a voltage of 380V. The cooling system flow is ≥400L/min ≤600L/min. This machine is perfect for those who need a low pressure die casting process that is accurate and cost-effective.
Packing and Shipping:
Packaging and Shipping
Low Pressure Die Casting Machine will be packaged in wooden crates and shipped by sea, air, or land. The crates will be designed to protect the machine from moisture and mechanical damage during its journey to the customer.
The crates will be secured with metal bands, and all shipping documents will be included in the package. The customer will be able to track the shipping progress with the included documents.
FAQ:
- Q: What is the brand name of Low Pressure Die Casting Machine?
A: The brand name of Low Pressure Die Casting Machine is DZ. - Q: What is the model number of Low Pressure Die Casting Machine?
A: The model number of Low Pressure Die Casting Machine is RD-5040-S. - Q: Where is Low Pressure Die Casting Machine made?
A: Low Pressure Die Casting Machine is made in China. - Q: Does Low Pressure Die Casting Machine have any certifications?
A: Yes, Low Pressure Die Casting Machine has CE and ISO certifications. - Q: What applications is Low Pressure Die Casting Machine suitable for?
A: Low Pressure Die Casting Machine is suitable for producing high precision aluminum die casting products.
